202K121-25-0 Heatshrink Boot Straight Lip

In stock
SKU : 202K121-25-0
Not Set
£5.49 £6.59

1pc

Please click the variations below to add to your product selection

0 Items in your selection £0.00 Selection Total
Back
Add Personalisation

  • Text
  • Number
  • Text & Number

Text Element

Save Back

Text & Number Element

Save Back

Number Element

Save Back
Skip Personalisation | Request a Callback

  • Buy 5 for £5.29 £6.35 per and save 4%
  • Buy 10 for £4.89 £5.87 per and save 11%
  • Buy 15 for £4.65 £5.58 per and save 15%
  • Buy 20 for £4.49 £5.39 per and save 18%
  • Buy 50 for £3.99 £4.79 per and save 27%
  • Buy 100 for £3.65 £4.38 per and save 34%
main product photo

TE Connectivity’s Heatshrink Boots are manufactured to be used coincide with other system 25 products like DR-25 heat shrink tubing and S1125 adhesive, this provide's a complete cable harness system. The 202k1 range has been specially made to offer the best fluid resistance at high temperatures as well as long-term heat resistance.

  • Semi-rigid

  • Chemical and abrasion resistant

  • Provides excellent sealing and strain relief

  • Resistance to long-term exposure at elevated temperatures

Show more

Details

General purpose moulded parts that provide durable strain relief, protection and an environmental seal when used with an adhesive. Available in straight and right angled types, these chemical and abrasion resistant heat shrink boots are made from a tough modified elastomer and meet the Def Stan 59-97 Issue 3 Type DE requirements.

These boots can be used with spin coupling backshells but may also be used wherever a connector offers a suitable rear mounting. It can be used for strain relief and sealing at connector-cable terminations as well as cable-to-cable transitions on cables and harnesses for military vehicles.

Features and Benefits:

  • Shink Ratio:2.3:1

  • Fluid Resistant Elastomer

  • Shrink Boot Type: Straight Lip

  • Shrink Temperature: +135°C

  • Operating Temperature Min: -75°C

  • Operating Temperature Max: +150°C

  • Compatible Cable Diameter Range: 5.6mm – 13.0mm

More Information
More Information
Quick Search Code 100353
Applications

  • Provides strain relief and insulation for wiring harnesses

  • Protects cables and connectors in harsh marine environments, preventing corrosion and water damage.

  • Used in high-reliability environments to provide protection against mechanical strain and environmental damage to cable assemblies and connectors.

Specification

  • Shink Ratio:2.3:1

  • Fluid Resistant Elastomer

  • Shrink Boot Type: Straight Lip

  • Shrink Temperature:135°C

  • Operating Temperature Min: -75°C

  • Operating Temperature Max:150°C

  • Compatible Cable Diameter Range: 5.6mm – 13.0 mm

Product Type Features:

  • Shell size: 21

  • Molded Part Type = Molded Boot

  • Material = Fluid Resistant Modified Elastomer

Body Features:

  • Angle: Straight

  • Compatible Cable Diameter Range: 5.6mm – 13.0 mm

Contact Features:

  • Family Name: 202K1

Downloads
File Icon Drawing (875.39 kB)
